Thermoplastic Valves
Globe Valves
The flow through a globe valve follows a course that takes nearly two 90° changes in direction. But, because the seating of a globe valve is parallel to the line of flow of the liquid, it can be used to throttle the flow to any required degree or to give positive shut-offs. The economy and dependability of the Asahi/America globe valve make it desirable for many applications where this pressure drop is not critical.
Resources:
Data Sheet
Specifications
Ideal Applications Include:
Chemical processing, aquariums, mining, water treatment, landfills
Specifications:
Sizes:
1/2″ – 4″
Models:
Flanged: 1/2″ – 4″*
Socket PVC: 1/2″ – 2″
PP: 1/2″ – 1″ (DIN also available)
Threaded PVC: 1/2″ – 2″
PP: 1/2″ – 1″
*2-1/2” – 4”: outside stem and yoke type
Bodies:
PVC and PP
Seals:
EPDM or FKM
Plug:
PP
- Used for efficient throttling of flow
- Positive shut-off
- Displays excellent flow regulating characteristics throughout the entire lift of the disc
- All sizes rated for full vacuum service
- EPDM seals. FKM optional
